IREEDA Clip-on Thermal Imager
Attach this thermal imaging clip-on to your existing night vision device, and the thermal channel is seamlessly overlaid onto the original image—combining the clarity of image intensification with the penetrating power of thermal imaging in one unified view.
- Unaffected by total darkness—thermal imaging reveals hidden targets where light no longer exists
- No need to replace your entire system—clip on and instantly upgrade your current equipment
- Detect temperature-contrasting targets earlier—gain the advantage, stay ahead of the moment
Advantages
- 35° Wide FOV
- Quick-Fusion for NVG
- Power-off by Flipping
- Hud Capablity
- Weight only 65g
- Bluetooth Remote Control
- Night Vision and Infrared Thermal Imaging
- Quick Disassembly and Calibration-free Use
- Compatible for PVS14 & PVS31 & GPNVG
- High-definition Jerry-C Clip-on Thermal Imager
Specification
|
Jerry-C Thermal Imager Clip-on System
|
||
|
Thermal Specifications
|
Resolution (Pixels)
|
640×512
|
|
Pixel Pitch (μm)
|
12
|
|
|
Frame Rate (Hz)
|
50
|
|
|
Optics Specifications
|
Magnification (×)
|
1
|
|
Lens System (mm)
|
11.5 F1.0
|
|
|
FOV (H × V) (°)
|
35×30
|
|
|
Image Mode and Functions
|
Image Modes
|
Adjustable Threshold, Auto Control, Highlight/Outline (Outline mode)
|
|
Auto Control
|
Brightness, Power off, Standby
|
|
|
Compass
|
support
|
|
|
External GPS
|
support (optional)
|
|
|
Power Supply
|
1×CR123A or Battery Pack
|
|
|
Battery Life (22°C)
|
3h (CR123A) / 10 h (Battery Pack)
|
|
|
Physical Specifications
|
Compatible
|
PVS-14 , BNVD (PVS-31A, GPNVG)
|
|
Min Fusion Distance (m)
|
10
|
|
|
Weight (w/o battery) (g)
|
65
|
|
|
Dimension (mm)
|
86(L)×65(W)×40(H)
|
|
|
Color Options
|
Brown, Black
|
|
|
Immersion
|
IP67
|
|
