Helmet Mounted Binocular Night Vision Goggles-The DA-PVS31 Advantage
The Helmet Night Vision Binoculars DA-PVS31 features an ergonomic and low-profile design. It offers better situational awareness than single tube goggles. Designed in direct collaboration with input from Special Forces operators, this binocular-type night vision goggle increases system resolution, greatly reduces head-borne weight, improves the system's center of gravity, provides additional operational utility, and enhances overall operator situational awareness compared to currently fielded dual-tube night vision binoculars.
DA-PVS31's Advantage
DA-PVS31 Helmet Mounted Binocular |
|
Rollover Detection
|
Automatically detect and power off when turning up
|
Battery Type
|
Lithium battery (CR123*1) /CR123*4 (external battery box)
|
Power Supply
|
2.6V - 4.2V
|
Installation
|
Head mounted(standard American helmet interface)
|
Control mode
|
ON/IR/AUTO
|
Battery Life
|
40-100hrs
|
Photocatode type
|
18 mm S-25
|
Resolution
|
>60lp/mm
|
SNR
|
>22
|
Magnification
|
1x
|
FOV
|
40°±2° (50°±2° )
|
Parallelism of Optical Axis
|
<0.1°
|
Lens System
|
25 mm, F/1.2
|
Coating
|
Multilayer broadband coating
|
Range of Focus
|
0.25 m to infinity
|
Focus Mode
|
Manual focus facility
|
Distance of Pupil
|
30 mm
|
Eyepiece Aperture
|
8 mm
|
Range of Visibility
|
-4DS~+4DS
|
Eye Spacing Adjustment
|
Arbitrary continuous adjustable
|
Eye Distance Adjustment Range
|
50-72mm
|
Eye Distance Locking Method
|
Manual locking
|
IR
|
850 nm, 20 mW
|
Operating Temperature |
-40℃ to +55°C
|
Humidity |
5%-95%
|
Environment Rating |
IP65 / IP67 (Optional)
|
Dimensions |
112* 105* 86 mm
|
Weight
|
490 g (Without battery)
|
