Product Introduction
Main features
Specification
|
ITEM |
DATA |
|
Generation IIT |
Gen2+ |
|
Fluorescent Screen |
P43/P45 |
|
FOV |
50°±2° |
|
Magnification |
1x ± 0.05x |
|
Optical Distortion |
≤2% |
|
Relative Illumination |
>70% |
|
Brightness Gain Adjustment |
manual |
|
Focus Range |
250mm~∞ |
|
Diopter Adjustment |
+2SD~-6SD |
|
Eye Relief |
≥25mm |
|
Exit Pupil Diameter |
≥14mm |
|
Installation Form |
head-mounted |
|
Power Supply |
battery compartment(CR123A×1/AA×1)+battery box(AA×4) |
|
Secondary Light Source |
930nm |
|
Rollover Detection |
automatic detection,power off when flipping up/lateral |
|
Security Functions |
low voltage alarm,strong light protection |
|
Working Hours |
15h~75h |
|
Weight(Battery Not Included) |
≤450g |
|
Dimensions(Eyecups Not Included) |
105mm×105mm×90mm |
|
Operating Temperature |
-20℃~+45℃ |
|
Waterproof Level |
IP65 |
