DA-PVS9 Aviation Pilot Night Vision Goggles Overview
IREEDA PVS-9 is a high-performance aviation night vision goggle, featuring an advanced optical system and lightweight composite shell for enhanced comfort and clear image quality. Designed to fit standard aerospace helmets, it is fully compatible with ANVIS lighting systems, enabling pilots to perform nighttime operations such as patrolling, observing, and searching. It supports night takeoff and landing, formation flying, landmark and terrain recognition, aerial reconnaissance, low-altitude search, and infrared detection. In addition to aviation use, the PVS-9 is suitable for night driving, medical rescue, surveillance, and data monitoring, offering versatility for various nighttime activities.
Product Features
1)Gen2+/Gen3 image intensifier tube;
2)Wide 40° ultra clear field of view;
3)Exceptional high-light performance due to auto-gating;
4)Fully compatible with the aircraft's ANVIS lighting system;
5)No moon and sky for 30m×30m target, detection distance 6km;
6)Improved Low-Light Performance;
7)Multipurpose: handheld, helmet support, head support;
8)Provides improved situational awareness and enhanced ergonomics;
DA-PVS9 Specification
|
Image Intensifier Tube
|
Euro Gen3
|
|
Resolution
|
≥60 lp/mm
|
|
Signal-to-Noise
|
＞20
|
|
FOM
|
＞1300 （1600/ 2000 as Optional)
|
|
Cathode Sensitivity
|
＞600
|
|
Magnification
|
1x |
|
Field of View
|
40°
|
|
F Number
|
1 |
|
Machine Resolution 1×10-3 Lx
|
1.59mrad
|
|
Optical Axis Parallelism
|
Horizontal divergence less than 60 ', height less than 20
|
|
Focus Range
|
250mm~infinity
|
|
Vision Focus Range
|
±4D
|
|
Eye-relief Distance
|
25mm
|
|
Exit Pupil Diameter
|
14mm
|
|
Eye Distance Adjustment Range
|
52~72mm
|
|
Adjustment Range
|
16mm front and rear adjustment, 16mm up and down adjustment, 8° pitch adjustment
|
|
Dimensions
|
108×131×93mm
|
|
Power Supply
|
3V (2 pieces AA batteries or 4 pieces AA batteries)
|
|
Weight (Bare Metal)
|
469g
|
|
Continue Working Time
|
40 hours
|
