Product Technical Parameters
Structural Form	Coaxial Structure
Focal Length	1000mm / 2000mm / 3000mm
Aperture	Φ200mm (for 1000mm/2000mm) / Φ300mm (for 3000mm)
Field of View	≥1.6° (for 1000mm) / ≥0.8° (for 2000mm) / ≥0.53° (for 3000mm)
Main Mirror Material	Standard: Quartz
	Optional: Sapphire
Coating	Standard: Aluminum + Protective Coating
	Optional: Gold/Silver + Dielectric Coating
Reflectivity	Single Mirror Reflectivity ≥85%
System Wavefront Aberration	RMS < 1/15λ @632.8
Parallelism	≤5"
Operating Wavelength Range	UV-Visible Band / Visible-Infrared Band

---
